| Rated voltage/current | 10(4),125,250VAC/6(2)A,380VAC For inductance Load,Cos φ=0.4 |
| Contact resistance | 25㏁ max.(initial value) |
| Insulation resistance | 100㏁ min.(at 500VDC) |
| Dielectric strength | 1000VAC , 50/60Hz For 1 minute between terminals of the same polarity |
| 1500VAC , 50/60Hz For 1 minute between current-carrying and non current-carrying metal parts |
| 1500VAC , 50/60Hz For 1 minute between each terminal and ground |
| Electrical life | 500,000 at 10A250VAC Resistive |
| Mechanical life | 10,000,000 operations min. (under rated conditions) |
| Operating Speed | 5mm/s to 0.5m/s |
| Degree of protection | IP66 |
| Ambient temperature rise | Max 30°C over ambient temperature at rated voltage/current |
| Conformed standards | Cenelec EN50041,EN50047,IEC337-1,VDE0660 |
| Operating temperature | -5°C- 65°C(with no icing) |
| Storage temperature | -5°C- 65°C(with no icing) |
| Ambient operating humidity | 95%RH Max |
| Shock Resistance | Mechanical durable :1000m/s2min. |
| Malfunction :300m/s2min. |
| Vibration frequency | Malfunction:10 t0 55hZ,1.5mm double amplitude |
| Terminal screw torsional force | 6-8 kgf - cm |
| Other screw torsional force | Cover 12-14 kgf - cm/Head 8-9 kgf-cm/Mounting 50-60 kgf/cm |
| Bare wire diameter | φ 2Max |
| Cable diameter | φ 12Max(IP 65 is use cable φ8-9 ) |
