- Safety switch with key
- Unit cannot be started when key is removed from the switch
- Precision spin-balanced aluminum impeller for smooth operation & minimal noise
- Clear collector bag with see-through window to view sawdust accumulation
- 5" heavy-duty PVC hose between body of fan & collector
- Collector body mounted on 3 heavy-duty rods
- Washable, extra fine 1 micron filter bag
- Quick release bag clamps with metal straps
- Intake screen guard to prevent large pieces from passing through
Specifications:
- Inlet diameter (1) 4" (102 mm)
- Airflow capacity 700 CFM
- Blower wheel diameter 9" (229 mm)
- Sound rating 75 TO 80 dB
- Bag diameter 15" (381 mm)
- Bag capacity 20 GAL (90.9 L)
- Motor 1 HP, 110 V, 1 Ph, 7 A
Overall dimensions:
- (L x W x H) 30 3/4" x 17" x 54 1/4" (780 x 430 x 1380 mm)
- Weight 76 LBS (34.5 kg)
